Design by Nuvolari-Lenard
Main deck saloon is divided into living and dining areas by a low-profile stairwell. Her spacious full beam owner’s suite features large circular windows letting in tremendous amounts of natural light.
The exterior layout is designed across one level with passageways leading to a foredeck pool area that offers more exterior lounging spaces and a massive pool with wide open views of the surrounding sea. BLISS can accommodate up to 10 guests in 5 luxurious ensuite staterooms.
Builder Palmer Johnson
Year 2014
Hull Type Semi Displacement
Hull Material Aluminum
Superstructure Material Aluminum
Exterior Styling Palmer Johnson & Nuvolari–Lenard
Interior Design Nuvolari & Lenard
Naval Architecture Palmer Johnson Engineering

2

Flag Cayman Islands
PRINCIPAL DIMENSIONS
LOA 52.13m
Breadth 8.72
Moulded Draft 2.94 m
Net Tonnage 148
Gross Tonnage 495

ACCOMODATION
Cabins 5
Guests 10
Crew 9
Crew Cabins 4 + Captain
TANK CAPACITIES
Main Fuel Oil 50,000 Liters
Extended Range Fuel Oil 10,600 Liters
Fresh Water 6,800 Liters
Black & Grey Water Holding 3,000 Liters
Machinery Lube Oil 700 Liters
Waste Lube Oil 2,400 Liters
Oily Bilge Tank 400 Liters
SPEED and RANGE
MAXIMUM SPEED 28 knots
CRUSING SPEED 24 Knots
RANGE @ 10.5 Knots 4600 Nm
RANGE @ 12 Knots 3200 Nm
RANGE @ 24 Knots 1100 Nm

ENGINES 2 x MTU 16V4000 M93L
Engine Power 3440kW (4615 BHP) @ 2,100 rpm
Engines hours 1667 (Oct 4,2018)

3

Gearbox 2 x remotely mounted gearboxes: ZF 9050 V / 2.958:1
Electrical System
Generators 2 x Kohler Diesel Generators, 125kVA, (100kW) each
230 / 400VAC / 50 Hz / 3 Phase and Neutral

Generators hours 3828 / 3475 (Oct 4,2018)
Shore Power 1 x Shore Power Converter, 125 kVA (100 kW), 400V, 3 Phase and neutral 50 Hz
Batteries Absorbed Glass Mat (AGM) Batteries, 24VDC
Stabilisation 2 x Sea keepers M26

2 x Sea Keepers SK 26( Installed in 2016 )

Watermaker 15,360 l/ per day

CLASSIFICATION
Lloyds Classification: X100A1 SSC Yacht Mono LDC HSC G6 [+] LMC MCA Large Commercial Yacht Code (LY2)

MACHINERY
Engines
• Model 2 x MTU 16V4000 M93L
• Engine Power 3440kW (4615 BHP) @ 2,100 rpm
• Engines hours 1667 / 1667 (Oct 4,2018)
Generators
• 2 x Kohler Diesel Generators, 125kVA, (100kW) each 230 / 400VAC / 50 Hz / 3 Phase and Neutral
• Generators hours 3828 / 3475 (Oct 4,2018)
Shore Power
• 1 x Shore Power Converter, 125 kVA (100 kW), 400V, 3 Phase and neutral 50 Hz
Batteries
• Absorbed Glass Mat (AGM) Batteries, 24VDC
Stabilizer System
• 2 x Sea keepers M26
• 2 x Sea Keepers SK 26( Installed 2016 )
• Single mode of operation at any speed; at rest, loiter and high speed
• Autonomous operation

4

Bow Thruster
• 2 x Bow thruster hydraulic type, mounted within tunnels
• 2 x aluminium tunnel, with mount for thruster drive unit
• 2 x drive units with propeller
• 3 x Control stations with joystick for full proportional control
Watermaker
• 15,360 l/ per day

NAVIGATION/COMMUNICATION EQUIPMENT
• The wheelhouse features five (5) 21inch flat screen LCD monitors (sunlight readable).
• Magnetic Compass
• Echo Sounding Equipment
• 2 x GPS
• Distance Measuring Log
• Gyro Compass
• Rudder Angle Indicators
• 2 x X-band Radar (with ARPA/ATA)
• Automatic Identification System (AIS)
• Electronic Charting System (ECS)
• Instrumentation pack inc: Speed and depth sensors, Air temp, sea water temp, barometric
pressure and anemometer
• 2 x Searchlights
• Navigation Lights (COLREGS 72)
• Autopilot
• EPIRB
• 2 x SART
• 2 x VHF transceivers with DSC
• Five (5) VHF slave control stations
• Iridium sat com transceiver
• GSM fixed cellular terminal (Voice/fax/data)
• Navtex receiver
• BNWAS system
• Inmarsat C transceiver
• Global Maritime Distress Safety System (GMDSS) suitable for Sea Area A3
• Nine (9) portable digital radios
• 2 x Portable VHF lifeboat radios

5

ENTERTAINMENT, NETWORK AND COMMUNICATION EQUIPMENT
The entertainment system comprises an Audio/Video-on-Demand (AVoD), distributed system with a centralized
media server. Local control of the system is available in all Owner and Guest areas.
Owners and guest space services include Satellite TV, VoD Movies, AoD Music, CCTV, Broadband Internet,
Map/ships info etc.
• Flat screen TV/monitors are installed for the Salon, Owner and guest accommodations.
• Local iPad provided for entertainment system control and internet access in all guest and Owner areas.
• An equipment rack for up to six (6) owner furnished satellite receivers is provided.
• 5.1 Theater type audio systems/speakers are installed for the Salon and Owner stateroom.
• Stereo type audio systems/speakers are installed for the guest staterooms.
• Marine grade speakers are provided for exterior spaces.
• Bluray/CD viewing/listening provided for Salon, Owner and guest accommodations.
• Aft deck and sundeck areas provided with stereo type audio systems/speakers per area.
• Crew Mess includes stereo type audio/speakers.
• All Crew TV’s are flat screen type.
NETWORKING
The system is based on a server with solid state drives
• Access to the internet is Via a Seatel 4009 VSat system or land line connection
• Wi-Fi access points are provided to give wireless networking capability in all Owners, guest and crew areas
for laptops and other Wi-Fi enabled products (PDA’s cellular devices etc)
• All owners and guest area have access to the internet without the use of a PC.
ALARM AND MONITORING SYSTEM
• 4 x LCD touch screen displays in the following locations: engineer’s cabin, engine room , crew mess and
wheelhouse.
• Data Acquisition Units interfacing with: Fire detection system, navigation lights, watertight
door monitoring, bilge alarms, diesel engine parameters, electrical generating parameters, tank level
monitoring, HVAC system, CCTV, hydraulics and miscellaneous alarms
• Integration with helm electronics
• Integration with the Closed Circuit TV (CCTV) System
FIRE DETECTION SYSTEM
• Consilium fire detection control panel with battery back up and located in the wheelhouse
• Smoke and Heat detectors and sounders cover the entire vessel as per regulations
• High Heat/Rate of Rise Sensors: Engine room, galley, garages, bow thruster space according to Class
• Manual call stations (break glasses)
CCTV SYSTEM
• Nine( 9 ) CCTV cameras.
• 1 x interface module
• 1 x viewing and camera control package
• 1 x monitoring screen in the crew mess

6

• 1 x Digital recording package
• Control of the system in the Pilot house.
AIR CONDITIONING SYSTEM
• Summer: outside +35°C w/ 80% RH
• Summer: inside +22°C +/-1° w/ 55% RH +/-5%
• Winter: outside 0°C
• Winter: inside +21°C +/-1°C
• Max sea water temperature: +32°C
SANITARY SYSTEM
• Tecma, white toilets, for the owner, guest bathrooms, day head. The toilets feature macerator flushing, and
have a vitreous china bowl unit
• Tecma, white toilets for the crew heads
• Tecma, bidet with a Zuchetti, bidet mixer
• 1 x Headhunter Tidal Wave TW-HMX-514, IMO approved sewage treatment plant
• 2 x sludge pumps, bronze housing, electric motor. The discharge pump is provided to pump the contents of
the holding tank to overboard or to the deck pump-out fitting.
Bilge and Fire Pumps:
• 1 x Bilge pump, bronze body centrifugal self-priming pump. Capable of local start and remote start from
wheelhouse
• 1 x Fire pump, bronze body centrifugal self-priming pump. The fire pump is located outside of the engine
room. Capable of local start and remote start from a foredeck locker switch and wheelhouse
• 1 x eductor unit
• 1 x diesel powered emergency bilge/fire FP bronze centrifugal pump, portable unit, located in the forward
PWC locker, Starboard side

FIRE STATIONS – BILGE/FIRE SYSTEM
• Hose: 38mm (1-1/2 inch), synthetic with brass pin lugs
• Nozzle: 38mm (1-1/2 inch), fog/stream, brass
FRESH WATER SYSTEM
• Watermaker, 15,360 lpd (4,057 gpd) @ 25°C
• 1 x Pressure set – 100 liter/min. Consisting of 2 x self-priming pumps, driven by individual TEFV electric
motors.
• 2 x Grundfoss, hot water rated circulation pump. Located in proximity to the water heaters. 1 x of the
pumps is a backup with valves
• 2 x water heaters, electric, reservoir type, with a minimum total capacity of 378 litres (100 gallons). The
water heaters include electric elements of 4,500-watt capacity each
• Cartridge type water filter unit. Provided with taste/odour cartridges

7
• 1 x pressure regulating valve and check valve for shore connection. The connection is located in the aft
main deck area of the vessel
• A silver Ionizer system and UV Lamp installed for potable water sterilization.
COMPRESSED AIR SYSTEM
• 2 x air compressors, air-cooled
• 1 x filter/regulator with gauge, polycarbonate body with guard
• 1 x airline filter, 25mm (1 inch), 250 PSI, metal with sight glass
• 1 x manually operated valve for draining
• 3 x 7.6m (25 foot) air hoses with end fittings. One in a machinery space, one on the foredeck and one in the
aft garage.
FIRE EXTINGUISHING SYSTEMS
• FM200 gas cylinder(s), valves, actuator, piping and nozzles
• Integration into the fire alarm and ship alarm system
• Stand alone FM200 discharge alarm
• Portable fire extinguishers, per MCA requirements
• 2 x fire suits, with helmet, mask, gloves, boots, oxygen supply and small fire axe. All per MCA requirements
• 1 x fire blanket, per MCA requirements, located within the galley space
• 1 x fire axe
ANCHOR EQUIPMENT – ANCHOR SYSTEM
• 2 x Maxwell, model VWC 11,000 vertical windlasses are bolted to aluminum insert plate. Each windlass has
a chromed bronze finish and is equipped with a hydraulic motor, rope gypsy, pendant control and band
brake
• 2 x Anchors are galvanised 250Kg Manson Marine
• The galvanized anchor chain two 160m (525 feet) lengths of chain. The bitter end secured within the chain
locker and can be released in the event of an emergency.
• Two stainless steel chain roller/tensioning assemblies
SAFETY EQUIPMENT
• 1 x Safety Management Plan provided with the vessel.
• Lifebuoys orange, yellow or red/white quarters
• 2 x 762mm (30-inch) diameter life rings with buoyant lines
• 2 x life rings with light and smoke canister. All life rings have recessed life ring holders
• Lifejackets :1 x per adult person, 2 x adult size spares, Four 4 child sizes
• Six (6) Rocket Parachute flares.
• 1 x set of Day Shapes, consisting of an anchor ball and a diamond
• 1 x medical locker
SWIM LADDER/LADDERS
The lazarette and chain lockers are provided with suitable ladders.

8

GALLEY & LAUNDRY EQUIPMENT
Galley:
• Extraction Hood: stainless steel
• Microwave oven Miele
• Gaggenau – induction hobs
• Oven – Rational
• Refrigerator: stainless steel front panel
• Freezer: stainless steel front panel
• Sink disposal
• Dishwasher Miele
• Gaggenau- vacuum drawer
Crew Mess:
• Dish Washer
• Refrigerator
• Wine Cooler
• Coffee machine
• Ice maker
Aft Deck Bar:
• Refrigerator
• Icemaker
Flybridge:
• Refrigerator
• Icemaker
• 2x Electric Grill
• Induction Cooktop
Laundry:
• 3x Washing Machines
• 3x Clothes Dryers
• 1 x Compact rotary iron

ACCOMODATION
• 1x Master, 2x VIP double, 2x Guest Twin cabins
• Dayheads
• Foyer and passageways
• Main Salon and Dining area
• Wheelhouse

9

• Private Lounge
• Exterior Public areas
• Owners and Guest stairwells

TENDERS & WATER TOYS
1. Tender PASCOE international shuttle 6.5m
2. Jet Ski
• SEADOO GTI SE 155
• SEADOO GTR 215
3. Seabob Gayago F7 – 2 pcs
4. Wake board “Liquid force 142 element”– 1 pcs
5. Fly board “ Zapata racing” – 1 pcs
6. Compressor for free dive – 1 pc
7. Water ski ”Connely quantum” – 1 pair
8. Water ski “Obrien freestyle” – 1 pair
9. Inflatable toys
• Fun Air Inflatable Swimming Platform
• FunAir Balcony Slide
• FunAir Swimming Pool Inflatable

Her engines have around 1670 hours, generators – around 3500 hours.

The asking price is Euro 25 mil, the yacht is not VAT paid.

https://www.youtube.com/watch?v=D_tAWlXYzC4

Name: BLISS
Year: 2014
Exterior: Nuvolari & Lenard
Interior Nuvolari & Lenard
Country:
Top speed:
Cruise speed:
Listing ID: 10524
